ASTM A182 F 316L Stainless Steel Flanges, SS Flanges, 316L Forged Flanges SS 316L Plate
SS Grades: F 304 - F 304L - F 304H - F 310 - F 310S - F 316 - F 316L - F 317 - F 317L - F 321 - F 321H - F 347 - F 347H - F 410 - F 446 - F 904L - F 51
We offer wide gamut of ASTM A182 F 316L Stainless Steel Flanges that are widely used in diverse industries. Fittings and flanges of SS 304 / 304L, 316/ 316L are made available on request of the customers. Can be made available in forms of Slip-On Flanges, Threaded Flanges, Weld Neck Flanges, Blind Flanges, Lap Joint Flanges, Socket Weld Flanges, Reducing Flanges, Plate Flanges, Fittings, Fasteners, etc Our gamut of products conform various standards such as the varied grades of stainless steel butt weld fittings that we supply are.
Standard: ASTM/ASME A/SA 182, ASTM/ASME A 240 SA240
Grade: F304, 304L, 304H, 316, 316L, 316Ti, 310, 310S, 321, 321H, 317, 347, 347H, 904L, Duplex stainless steel UNS S31803, 2205, Super Duplex stainless steel UNS S32750
ASTM A182 F 316L Stainless Steel Flanges Dimensional Range & Standard Specification
Specification:StandardsDesignation
| ASTM | A 182 |
| ASME | SA 182 |
ASTM A182 F 316L Stainless Steel Flanges Production Range
| Specification | ASTM A182 / A240 & ASME SA182 / SA240 |
| Grade | 316, 316L, 316H, 316LN |
| Standard | ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc. |
| Size | 1/8" to 36" |
| Dimensions | ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
| Class / Pressure | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
Type of ASTM A182 F 316L Stainless Steel Flanges we manufacture:
High Pressure Forged Pipe Fittings / Threaded and Socket Weld Pipe FittingsManufacturer ofSize
| ASTM A182 F 316L Slip-On Flanges | ASTM A182 F 316L Threaded Flanges | 1/8" - 36" Raised Face or Flat Face |
| ASTM A182 F 316L Weld Neck Flanges | ASTM A182 F 316L Socket Weld Flanges | |
| ASTM A182 F 316L Blind Flanges | ASTM A182 F 316L Reducing Flanges | |
| ASTM A182 F 316L Lap Joint Flanges | ASTM A182 F 316L Plate Flanges |
Flanges according to ASTM A182 Grade F304, F304L F316L
Pipes according to ASTM A312 Grade TP304, TP304L, TP3016L
Fittings according to ASTM A403 Grade WP304, WP304L, WP316L
ASTM A182 F 316L Stainless Steel Flanges price
| Click here for stainless steel pipe price list (updated price list) | |
| ASTM A182 F 304 stainless steel flange US $0.5-500 / Piece (FOB Price) 304 and 316 astm a182 f316l stainless steel flange US $1-355 / Piece (FOB Price) ASME B16.5 stainless steel a182 wp304 plate slip-on flange US $1-300 / Piece (FOB Price) ASTM A 182 F304 forged wn flange US $1000-2500 / Ton (FOB Price) F 316 Stainless Steel Blind flange US $100-1200 / Piece (FOB Price) stainless steel pipe flanges 304 316 304l US $0.01-260 / Piece (FOB Price) stainless steel 304L plate flange US $3-8 / Kilogram (FOB Price) 304L 304 A CLASS 2500 WELDING NECK STAINLESS STEEL FLANGE FOR TUBE US $2400-3500 / Metric Ton (FOB Price) astm a182 ansi b16.5 304l 316l forged stainless steel flange US $1-100 / Piece (FOB Price) Top quality 304l stainless steel flange US $1.5-200 / Piece (FOB Price) Astm a182 Ss04 304l 316 316l blind Flange US $1-500 / Piece (FOB Price) ASTM A403 WP317 ELBOW, WP316L US $0.45-8000 / Piece (FOB Price) F304 / 316L Stainless Steel Flange US $0.2-120 / Piece (FOB Price) A105 SS400 ST37.2 CT20 304 316 321 Stainless Steel Flange US $0.2-120 / Piece (FOB Price) DIN2642 PN10 PLATE FLANGE US $20-100 / Piece (FOB Price) 904L Plate Flange Flanges manufacturer from India ASME 16.5 US $0.15-10 / Piece (FOB Price) | Standard 304 Stainless Steel Threaded Flange US $20-50 / Piece (FOB Price) 304 stainless steel flange US $1-400 / Ton (FOB Price) ASTM A182 ANSI Stainless Steel Forged SS 304 SW Flange US $1-999 / Piece (FOB Price) BS4504 304 316 Stainless Steel Flange US $1-100 / Piece (FOB Price) 2015 HOT SALE JIS 10K 304 SW Flange US $878.36-1812.23 / Ton (FOB Price) 2015-16 new products High Pressure [Welded neck /Plate flanges] 304 316 US $500-1500 / Ton (FOB Price) 304 stainless steel forged flanges manufacturer US $10-1000 / Piece (FOB Price) ansi b16.5 ss 316l flange US $0.1-300 / Piece (FOB Price) ansi 150lb ss dn50 pn10 steel flange US $1-50 / Piece (FOB Price) 316 SS flange JIS standard flange US $999-1499 / Ton (FOB Price) AISI316H SS blind flange US $1-25 / Piece (FOB Price) A182 F316 SS LONG WELDING NECK RF flange US $30-3000 / Piece (FOB Price) |
Useful Information:
| Stainless Steel | Tradename | UNS no. | Werkstoff No. | Density (g/cm3) |
| 316 | 316 Stainless | S31600 | 1.4401 | 8.00 |
| 316L | 316L Stainless | S31603 | 1.4404 | 8.00 |
| 316H | 316H Stainless | S31609 | 1.4919 | 8.00 |
| 316Ti | 316Ti Stainless | S31635 | 1.4571 | 8.00 |
High oxidation resistance
Better corrosion resistance than Type 304 stainless steel
Excellent pitting resistance
Strong resistance to most chemicals involved in the paper and textile industries
316/316L is the most used austenitic stainless steel in the chemical process industry, the higher nickel and molybdenum content in this grade allows it to demonstrate better overall corrosion resistant properties than 304/304L, especially with regard to pitting and crevice corrosion in chloride environments. It also offer higher creep, stress rupture and tensile strength in elevated temperature. Type 316L is an extra-lower carbon version of type 316 that eliminates harmful carbide precipitation due to welding. Generally all Merinox tubing is dual- certified to meet both 316 and 316L.
Composition of ASTM A182 F 316L Stainless Steel Flanges
Table 1. Composition ranges for 316 grade of stainless steels.GRADECMNSIPSCRMONIN
| 316 | Min | - | - | - | 0 | - | 16.0 | 2.00 | 10.0 | - |
| Max | 0.08 | 2.0 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | 0.10 |
Table 2. Mechanical properties of 316 grade stainless steels.GRADETENSILE STR
(MPA) MINYIELD STR
0.2% PROOF
(MPA) MINELONG
(% IN 50MM) MINHARDNESSROCKWELL B (HR B) MAXBRINELL (HB) MAX
| 316 | 515 | 205 | 40 | 95 | 217 |
Physical Properties of ASTM A182 F 316L Stainless Steel Flanges
Table 3. Typical physical properties for 316 grade stainless steels.GRADEDENSITY
(KG/M3)ELASTIC MODULUS
(GPA)MEAN CO-EFF OF THERMAL EXPANSION (ΜM/M/°C)THERMAL CONDUCTIVITY
(W/M.K)SPECIFIC HEAT 0-100°C
(J/KG.K)ELEC RESISTIVITY
| 316 | 8000 | 193 | 15.9 | 16.2 | 17.5 | 16.3 | 21.5 | 500 | 740 |
Table 4. Grade specifications for 316 grade stainless steels.GRADEUNS
NOOLD BRITISHEURONORMSWEDISH
SSJAPANESE
JISBSENNONAME
| 316 | S31600 | 316S31 | 58H, 58J | 1.4401 | X5CrNiMo17-12-2 | 2347 | SUS 316 |
Corrosion Resistance of ASTM A182 F 316L Stainless Steel Flanges
Excellent in a range of atmospheric environments and many corrosive media - generally more resistant than 304. Subject to pitting and crevice corrosion in warm chloride environments, and to stress corrosion cracking above about 60°C. Considered resistant to potable water with up to about 1000mg/L chlorides at ambient temperatures, reducing to about 500mg/L at 60°C.
316 is usually regarded as the standard "marine grade stainless steel", but it is not resistant to warm sea water. In many marine environments 316 does exhibit surface corrosion, usually visible as brown staining. This is particularly associated with crevices and rough surface finish.
Heat Treatment of ASTM A182 F 316L Stainless Steel Flanges
Solution Treatment (Annealing) - Heat to 1010-1120°C and cool rapidly. These grades cannot be hardened by thermal treatment.
